Tektronix 3 Series User Manual

Field or control Description
Data Sets to trigger when the specified data bits condition occurs.
T
ap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values. See Binary, decimal, hex, and octal virtual
keypads on page 228.
Available when Trigger When = anything except Inside Range or Outside Range.
Data High Sets the high value of the data pattern range on which to trigger.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When = Inside Range or Outside Range.
Data Low Sets the low value of the data pattern range on which to trigger.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When = Inside Range or Outside Range.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change in data or bit fields.
Use the B knob to change the value of the digit(s) in the selected field.
Mode & Holdoff
Trigger Mode determines how the instrument behaves in the absence or presence of a trigger event.
Holdoff sets the amount of time the oscilloscope waits after a trigger event before detecting and
triggering on the next trigger event.
For additional information on Trigger Mode, Holdoff, forcing a trigger, and the Trigger Frequency
Counter see Mode and Holdoff panel on page 226.
Act On Trigger
Set the actions the instrument takes when a trigger event occurs.
For additional information on the Act On Trigger panel see Act On Trigger configuration
menu on page 227.
Audio serial bus trigger settings panel
Use the Audio bus menu (optional) to set up and display Audio T
ype I2S, Left Justified (LJ), Right Justified (RJ), or TDM Audio serial bus
waveforms.
Note: Requires option SRAUDIO.
Field or control Description
Source Select the Audio bus on which to trigger
.
Trigger On Select the type of information on which to trigger.
Word Sets the audio word channel on which to trigger (Either, Left, Right).
Available when Trigger On = Data.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 201
