Tektronix AWG5200 Series Technical Reference

Specifications
Table 11: Harmo
nic distortion (AC Amplified output path)
AC Amplified output path
At –5 dBm
2nd harmonic
10MHzto4GHz
< –65 dBc at Pout = –15 dBm
10MHzto4GHz
< –50 dBc at Pout = 0 dBm
10MHzto4GHz
< –26 dBc at Pout = 10 dBm
3rd harmonic
10 MHz to 50
0MHz
< –75 dBc at
Pout = –15 dBm
500 MHz to
4GHz
< –65 dBc at Pout = –15 dBm
10 MHz to
4GHz
< –48 dBc at Pout = 0 dBm
10 MHz to
4GHz
< –28 dBc at Pout = 10 dBm
Table 12: SFDR operating at 2.5 GS/s (DC High Bandwidth, 500 mV
pp
)
2.5 G S/s In band performance Adjacent band performance
Analog channel
output frequency
Measured across
Specification
Measured across
Specification
100 MHz 10 to <1250 MHz –80 dBc
––
10 to <155 MHz 10 to <1250 MHz –80 dBc
––
155 to <1000 MHz 10 to <1000 MHz –53 dBc 1000 to <1250 MHz –60 dBc
1000 to <1250 MHz 1000 to <1250 MHz –51 dBc 10 to <1000 MHz –50 dBc
Tab
le 13: SFDR operating at 5 GS/s (DC High Bandwidth, 500 mV
pp
)
5 GS/s In band performance Adjacent band performance
Ana
log channel
output frequency
Mea
sured across
Specification
Mea
sured across
Specification
10
0MHz
10
to <1250 MHz
–8
0 dBc
12
50 to <2500 MHz
–7
5dBc
10 to <310 MHz 10 to <1250 MHz –80 dBc 1250 to <2500 MHz –70 dBc
310 to <1250 MHz 10 to <1250 MHz –67 dBc 1250 to <2500 MHz –64 dBc
1
0 to <1250 MHz
–
38 dBc
1
250 to <2000 MHz
1
250 to <2000 MHz
–
53 dBc
1250 to <2000 MHz –58 dBc
2000 to <2500 MHz 2000 to <2500 MHz –33 dBc 10 to <2000 MHz –31 dBc
AWG5200 Series Technical Reference 13
