Tektronix AWG7082C User Manual

Troubleshooting
Table 4-6: Diagnostics error codes (cont.)
Error code Error log message
Possible defect
on board Note
151000015
Analog Level Diag CH2 5db attenuator gain balance
failed.
OUT10G OUT10G: K610, K710
151000016
Analog Level Diag CH2 5db attenuator gain balance
failed.
OUT10G OUT10G: K610, K710
151000017
Analog Level Diag CH2 10db attenuator gain balance
failed.
OUT10G OUT10G: K620, K720
151000018
Analog Level Diag CH2 20db attenuator gain balance
failed.
OUT10G OUT10G: K630, K730
151000019
Analog Level Diag CH2 filter 50mhz gain balance failed. OUT10G OUT10G: K660, K760
151000020
Analog Level Diag CH2 filter 200mhz gain balance
failed.
OUT10G OUT10G: K670, K770
151000021
Analog Level Diag CH2 amp gain balance failed. OUT10G OUT10G: U800
1520M0001
Marker Level Diag CH2 M ARKER M offset failed. OUT10G
U120, U170, U230, U240, U330,
U340
1520M0002
Marker Level Diag CH2 MARKER M positive offset
failed.
OUT10G
U120, U170, U230, U240, U330,
U340
1520M0003
Marker Level Diag CH2 MARKER M negative offset
failed.
OUT10G
U120, U170, U230, U240, U330,
U340
1520M0004
Marker Level Diag CH2 MARK ER M amplitude failed. OUT10G
U120, U170, U230, U240, U330,
U340
1520M0005
Marker Level Diag CH2 MARKER M amplitude
correction failed.
OUT10G
U120, U170, U230, U240, U330,
U340
190000000
TekLink receive error Send=TR Recv=RV
TR:Transmition data RV:Receive data
MIO MIO: U300
AWG7000B and AWG7000C Series Service Manual 4–63
