3. Termination, 50 Ω (three required)
Impedance 50 Ω; connectors:
female BNC input, male BNC
output
Tektronix part number
011-0049-02 (1 GHz)
Signal termination for channel
delay test, trigger sensitivity
4. Cable, Precision 50 Ω Coaxial (three required)
50 Ω, 36 in, male-to-male
BNC connectors
Tektronix part number
012-0482-00
Signal interconnection,
Trigger out, time qualified
trigger, timebase delay time,
baud rate limit, bandwidth,
input resistance, delta time,
clock recovery, generator
leveling
5. Connector, Dual-Banana (two required)
Female BNC-to-dual banana Tektronix part number
103-0090-00
Various accuracy tests, input
resistance
6. Generator, DC Calibration
Instrument bandwidth
≤20 GHz:Variable amplitude
to ±7 V; accuracy to 0.1%
Fluke 9500B
1
Checking DC offset, gain,
measurement accuracy, probe
compensation out, and
maximum input voltage
Instrument bandwidth
>20 GHz:Variable amplitude
to ±7 V; accuracy to 0.1%
Keithley 2400
7. Generator, Calibration
500 mV square wave
calibrator amplitude; accuracy
to 0.25%
Fluke 9500B
1
Checking accuracy of signal
out, trigger out
8. Timer-counter
10 MHz and 100 MHz, 1 s
gate
Advantest R5360 Checking long-term sample
rate and delay time accuracy
1
Fluke 9500B/1100, 9500B/3200, or 9500B/2200 and an output head (9510 or 9530) appropriate for the bandwidth of the instrument being tested.
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 117
