Tektronix DPO70000C/DX Series Technical Reference

31. Logic probe
P6717 or P6780 Logic Probe Tektronix part P6717 or
P6780
Checking digital channels
32. Adapter
BNC “T”, male to 2 females Tektronix part number
103-0030-xx
Checking DC gain and offset
accuracy
33. Attenuator 2X
Ratio: 2X; impedance 50 Ω;
connectors: female input,
male output
BNC ≤ 2 GHz Tektronix part
number 011-0069-xx
Checking output signals
34. Source measure unit
Source and Measure < 1 A
and <5 V
Keithley 2400 SourceMeter
with Model 8605 test leads
Checking TekProtect
35. Instrument controller
GPIB controller PC with GPIB or Ethernet
interface
Checking TekProtect
Test record
Photocopy the test record tables and use them to record the performance test
results for your instrument.
Table 5: Test information
Item Recorded value
Instrument Serial Number
Technician
Certificate Number
Date of Calibration
Temperature
RH %
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 121
