22. Adapter
SMA "T", male to 2 SMA
female
Tektronix part number
015-1016-00 (18 GHz)
Checking delta time
measurement accuracy
23. Adapter
SMA female to BNC male Tektronix part number
015-0572-00 (4 GHz)
Used to test delta time
measurement accuracy and
trigger sensitivity
24. Adapter
BNC male to female elbow Tektronix part number
103-0031-00
Checking delta time
measurement accuracy
25. Termination
Short circuit, SMA connector,
female
Tektronix part number
015-1021-00 (18 GHz)
Checking delta time
measurement accuracy
26. Attenuator, 2X
Ratio: 2X; impedance 50 Ω;
connectors: female BNC
input, male BNC output
Tektronix part number
011-0069-02 (2 GHz)
Checking delta time
measurement accuracy, pulse
trigger accuracy, time
qualified trigger, trigger
sensitivity, and channel
isolation
27. Digital Multimeter
Ohms: <60 Ohms Keithley 2700 Checking input impedance
28. Cable, coaxial
50 Ω, 39.37 in (1.0 m), male-
to-male SMA connectors
50 Ω, 60 in (1.5 m), male-to-
male SMA connectors
Tektronix part number
174-1341-00 Tektronix part
number 174-1428-00
Checking analog bandwidth
and delta time measurement
accuracy. Checking ≥ 4 GHz
models serial trigger baud rate
limits
29. Mouse or keyboard
Tektronix part numbers:
119-7054-xx (mouse)
119-7083-xx (keyboard)
Used to input test selections
30. Probe tip adapter
BNC female to square pin
adapter, 50 Ω
Tektronix part number
067-1734-00
Checking digital channels
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
120 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
