Specifications (MSO70000C/DX, DPO70000C/DX, and

DPO7000C series)

This chapter contains specifications for the instrument. All specifications are

guaranteed unless noted as "typical." Typical specifications are provided for your

convenience but are not guaranteed. Specifications that are marked with the

symbol are checked in this manual. All specifications apply to all models unless

noted otherwise.

<4 GHz models. Includes the DPO7000C Series instruments unless noted

otherwise.

Table 1: Instrument Model Numbers (<4 GHz)

DPO

7354C (3.5 GHz)

7254C (2.5 GHz)

7104C (1 GHz)

7054C (500 MHz)

≥4 GHz, ≤20 GHz models. Includes the MSO70000C and DPO70000C Series

instruments unless noted otherwise.

Table 2: Instrument Model Numbers (≥4 GHz, ≤20 GHz)

MSO DPO

70404C (4 GHz) 70404C (4 GHz)

70604C (6 GHz) 70604C (6 GHz)

70804C (8 GHz) 70804C (8 GHz)

71254C (12.5 GHz) 71254C (12.5 GHz)

71604C (16 GHz) 71604C (16 GHz)

72004C (20 GHz) 72004C (20 GHz)

>20 GHz models. Includes the MSO70000DX and DPO70000DX Series

instruments unless noted otherwise.

Table 3: Instrument Model Numbers (>20 GHz)

MSO DPO

72304DX (23 GHz) 72304DX (23 GHz)

72504DX (25 GHz) 72504DX (25 GHz)

73304DX (33 GHz) 73304DX (33 GHz)

≥4 GHz models. Includes all MSO70000C/DX and DPO70000C/DX Series

instruments.

MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 1

Tektronix DPO70000C/DX Series Technical Reference
