Input and output ports
DVI Video port >20 GHz models: A female Digital Visual Interface (DVI-D) compatible port
≤20 GHz models: A female Digital Visual Interface (DVI-I) compatible port
VGA port, DX models only A female Video Graphics Array (VGA) compatible port
Passive eSATA Port Instrument must be powered down to make connection
COM1 and COM2 serial ports 9 pin D-Sub ports, use NS16C550-compatible UARTS, transfer speeds up to 115.2 kb/s.
DX models have only COM1.
Keyboard and Mouse ports PS-2 compatible, instrument must be powered down to make connection
LAN port RJ-45 connector, supports 10 base-T, 100 base-T, and Gigabit Ethernet
External audio ports External audio jacks for microphone input and line output
USB ports >20 GHz models: Four rear panel and 2 front panel USB 2.0 connectors. On DX models, two of the
rear panel connectors are USB 3.0/USB 2.0
≤20 GHz models: Four side or rear panel and 1 front panel USB 2.0 connectors
GPIB port IEEE 488.2 standard interface, listener or controller
Data storage specifications
Hard disk
>20 GHz models Waveforms and setups are stored on the hard disk.
2.5-inch SATA hard disk, drive capacity is ≥300 GB. DX models use a ≥300 GB solid state drive. C
models use a ≥500 GB hard disk drive.
≤20 GHz models 2.5-inch SATA hard disk, drive capacity is ≥160 GB.
Input-output port specifications (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 73
