Installation
Optional accessories (cont.)
Accessory Description
Tektronix part
number
FlexRay, CAN, and LIN serial triggering and
analysis application module
This module enables triggering on packet level
information in FlexRay, CAN, and LIN buses.
Also, it provides digital views of the signal, bus
views, packet decoding, search tools, packet
decode tables with time stamp information and
eye diagram analysis software.
DPO4AUTOMAX
Computer triggering and analysis application
module
This module enables triggering on RS-232,
RS-422, RS-485 and UART serial buses.
Also, it provides digital views of the signal,
bus views, packet decoding, search tools,
and packet decode tables with time stamp
information.
DPO4COMP
Embedded serial triggering and analysis
application module
This module enables triggering on packet
level information on I
2
C and SPI serial buses.
Also, it provides digital views of the signal,
bus views, packet decoding, search tools,
and packet decode tables with time stamp
information.
DPO4EMBD
Ethernet serial triggering and analysis
application module
This module enables triggering on 10BASE-T
and 100BASE-TX buses. Also, it provides
digital views of the signal, bus views, packet
decoding, search tools, and packet decode
tables with time stamp information.
NOTE. ≥350 MHz bandwidth models are
recommended for 100BASE-TX .
DPO4ENET
Limit and mask test application module This module supports limit t esting and testing
on custom masks or standard telecom or
computer masks.
NOTE. ≥350 MHz bandwidth models are
recommended for Telecomm standards
>55 Mb/s. 1 GHz bandwidth models are
recommended for high-speed (HS) USB.
DPO4LMT
Power analysis application module
This module supports measurements of power
quality, switching loss, harmonics, ripple,
modulation, safe operating area, and slew rate
(dV/dt and dI/dt).
DPO4PWR
Universal Serial Bus triggering and analysis
application module
This module enables triggering on packet level
information on USB 2.0 serial buses. Also, it
provides digital v iews of the signal, bus views,
bus decoding data in hex, binary, and ASCII,
search tools, and packet decode tables with
time stamp information.
NOTE. 1 GHz bandwidth models are required
for high-speed (HS) USB . Differential probe is
required.
DPO4USB
MSO4000B and DP O4000B Series Oscilloscopes User Manual 3
