MSO64 standard accessories
Item Quantity Tektronix part number
Installation and Safety Manual 1 071-3579-xx
TPP1000 Passive Voltage Probe (1 GHz bandwidth). One per channel TPP1000
Front cover 1 200-5406-xx
Accessory pouch (attached to front cover) 1 016-2106-xx
Mouse (wired with USB connector) 1 119-7054-xx
Power cord 1 Depends on region
Calibration certificate 1 N/A
Report of factory installed licenses 1 N/A
Safely rotate the handle
Use the correct process to eliminate the chance of pinching your thumb or rear-panel-connected cables while rotating the handle.
CAUTION. Hold the top of the handle to rotate the handle on the instrument. Do not hold the handle from the sides and rotate, as
this can pinch the base of your thumb between the handle and the case.
If you have routed any cables between the handle and the case, be careful when rotating the handle so that you do not pinch the
cables.
Install your instrument
24 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
