Tektronix RSA306 Technical Reference

Performance ver
ification
Table 7: Amplitude accuracy, –13 dBm reference level measurements (cont.)
Center/signal
frequency
RSA306 reading,
dBm
Power meter value,
dBm
Error (RSA306 –
Pwr meter), dB
4.571 GHz
4.629 GHz
4.631 GHz
4.749 GHz
4.751 GHz
4.959 GHz
4.961 GHz
5.699 GHz
5.701 GHz
5.804 GHz
5.806 GHz
6.200 GHz
Table 8: Amplitude accuracy, –30 dBm reference level measurements
Center/signal
frequency
RSA306 reading,
dBm
Power meter value,
dBm
Error (RSA306 –
Pwr meter), dB
9kHz
20 kHz
50 kHz
100 kHz
300 kHz
1MHz
3MHz
10 MHz
20 MHz
22 MHz
100 MHz
699 MHz
701 MHz
1GHz
1.849 GHz
1.851 GHz
2.339 GHz
