Status and Events
TDS200, TDS1000/2000, TDS1000B/2000B, TPS2000 Programmer
3-11
MEASUREMENT:IMMED:VALUE?
Processing Time
Acquiring Waveform Data
ACQUIRE:STATE ON
Figure 3- 7: Command processing without using synchronization
The acquisition of the waveform must be completed before the
measurement can be taken on the acquired data. This is achieved by
synchronizing the program so that the measurement command is not
processed by the oscilloscope until the acquisition is complete.
Figure 3--8 shows the desired processing sequence.
MEASUREMENT:IMMED:VALUE?
Processing Time
Acquiring Waveform Data
ACQUIRE:STATE ON
Figure 3- 8: Processing sequence with synchronization
Four commands can be used to synchronize the opera tion of the
oscilloscope with your applicati on program: *WAI, BUSY?, *OPC,
and *OPC?. The *OPC? query i s the most sim ple.
Using the *WAI Command
You can force commands to execute sequentially by using the *WAI
command. This command forces completion of the previous
commands before processing new ones.
