Tenda A33 User Manual

Version1.0
37
6 Re-extend
You can configure this function only in the Extender Mode.
You can try re-extending the WiFi network under the following circumstance:

When the WiFi extender fails to extend the WiFi network of the upstream device;

When you have successfully extended a WiFi network but want to extend another one;

When you only successfully extended the WiFi network in a single frequency band and are to
extend the WiFi network in the other frequency band.
Configuration procedure:
Step 1 Plug the WiFi extender into a power outlet near the router in the same room.
Step 2 Re-extend your WiFi network.
1. Start a web browser on the computer connected to the WiFi extender, and enter
re.tenda.cn in the address bar to access the web UI of the WiFi extender.
2. Click Re-extend.
3. If you want to re-extend 2.4 GHz WiFi, please select the WiFi name of 2.4 GHz WiFi to be
extended, for example, “Tenda-123456”, and click Next. Otherwise, you can click Skip 2.4
GHz.

Tenda A33 Specifications

General

Maximum data transfer rate	1000 Mbit/s
Antennas quantity	2
Antenna gain level (max)	5 dBi
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Frequency band	5/2.4 GHz
Signal strength	20 dBm
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	2402 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA-PSK, WPA2-PSK, WPA3
Power LED	No
Product type	Network repeater
Product color	White
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	CE, RoHS
Certification	FCC
DC output current	1 A
DC output voltage	12 V
Power consumption (typical)	11 W

Weight and Dimensions

Depth	72 mm
Width	123 mm
Height	47.5 mm
