SMW Oven Service ManualLower Oven Section
REMOVING A HALOGEN LAMP HOLDER
Refer to Figure 12 for the following steps.
1. Turn off the electrical power to the oven.
2. Remove the oven racks.
3. Remove the oven rack support for the halo-
gen lamp holder you are removing.
CAUTION: Make sure that the halogen bulb
is cool before you remove it in the next step.
4. Pull the lamp cover out of the halogen lamp
holder and remove the bulb.
5. Pry the lamp holder out of the oven liner and
cut the wires approximately 2" from the lamp
holder body. CAUTION: Be careful not
to chip or scratch the oven liner when
you pry the lamp holder out of the cut-
out.
6. Cut the plug off the new lamp holder.
7. Connect the cut wires to the new lamp holder
with two red inline splices. After you connect
the wires, pull on them to make sure that the
inline splices are secure.
8. Gently pull the lamp holder wires up into the
plenum area until you can see the red wire
splices in the plenum area.
9. Reassemble the oven.
TECH TIP!!
Make sure that the two red inline splices are in
the top plenum area and not in the oven heat
zone.
When you work on the oven, be careful
when handling the sheet metal parts.
There are sharp edges present and you can
cut yourself if you are not careful.
CAUTION
WARNING
Turn off the electrical power circuit to the
oven at the main junction box before ser-
vicing this unit.
