Page 54
SMW Oven Service ManualLower Oven Section
REMOVING A BLOWER
1. Turn off the electrical power to the oven.
2. To make servicing easier, remove the oven
door (see Page 57).
When you work on the oven, be careful
when handling the sheet metal parts.
There are sharp edges present and you
can cut yourself if you are not careful.
CAUTION
WARNING
Turn off the electrical power circuit to the
oven at the main junction box before ser-
vicing this unit.
3. To remove the lower blower (see Fig-
ure 20):
a) Remove the oven from the wall.
b) Remove the rear panel from the oven.
c) Remove the four bracket screws (1,2,6, &
7) from the back of the oven.
d) Remove the three blower screws (3, 4, &
5) from the bracket and remove the mo-
tor.
e) Loosen the wire ties and remove the two
motor wires from the rest of the wire har-
ness.
f) Install the new blower in the mounting
bracket, mount the assembly to the back
of the oven, and connect the wires.
g) Install the motor wires in the wire harness
ties with the rest of the wires and dress
them neatly.
4. Reassemble the oven.
