Page 57
SMW Oven Service ManualLower Oven Section
REMOVING AN OVEN DOOR
Refer to Figure 30 for the following steps.
1. Open the door to its fully open position.
2. Raise the hinge latch over the hook on each
of the hinges.
Position Up To
Remove Door
Position Down
To Close Door
Hinge Latch
Figure 23
3. To remove the door:
a) Grasp the door by the sides toward the
back and raise the front of the door sev-
eral inches (there will be some resistance
in the spring mechanism because the hinge
is locked).
b) When the door is high enough, lift it until
the hinges clear the indents, and pull it out
of the slots in the front frame.
