µP-D Controller Menu Guard Functions 4-29
Menu Guard Functions
NOTE: An access code is required to enter the
Guard menu to prevent unauthorized personnel from
tampering with the programmable features.
The Guard menu is used to set many programmable features
including:
• Unit Configuration
• Customer Configuration
• Container Identification Number
• Unit Serial Number
• Date and Time
• Unit and Special Hourmeters
• Economy Mode ECMAX and ECMIN
• Change Temperature Display Units (C/F)
• Sensor Grades
The controller turns OFF all control outputs and suspends
normal operation when the Guard menu is entered.
When the Guard Menu is exited, the controller resets and
then restarts the unit. This is necessary to be certain that all
changes in the programmable features are activated.
Navigating Menu Guard Screens
With the unit On/Off switch ON and the controller showing
the Standard Display:
1. Press the SELECT key to enter menu (display shows
“MENU <--->”).
2. Press DOWN key until display shows “MENU GUARD”.
3. Press the SELECT key to enter GUARD submenu (dis-
play shows “GUARD <--->”).
4. Press the DOWN key. Display shows “GUARD 0000”
with left “0” flashing. A flashing digit indicates the digit
that can be changed.
5. Enter the current access code “0007”.
a. Press and release the SELECT key three times to
scroll the flashing digit (“0”) to the right digit.
b. Press and release the DOWN key three times to scroll
the flashing digit to “7” (display now shows
“GUARD 0007”).
c. Press the ENTER key to load the code and access the
Guard menu. The display will briefly show
“GUARD LOAD” and then show “GMENU <--->”.
MENU TEST Screen Flow Diagram (See Display Acronym Definitions on pages 4-4 to 4-6)
