4-46 Alarm Codes, Descriptions and Corrective Actions µP-D Controller

CSR-20 & CSR-40, September 1999

Alarm Codes, Descriptions and Corrective Actions

Code Description Corrective Action

00 No Fault • None Required

02 Ambient Temperature Sensor Failure • Check the sensor by selecting it using the View

(Check Alarm) menu. If the display shows [- - - -], the sensor is

defective or the circuit is open or shorted.

• Indicates a problem exists with this sensor

or its wiring. The sensor is reading out-of- • Check sensor by substitution. Be sure sensor

range; or appears to be open or shorted. polarity is correct.

• This sensor does NOT require ice bath • Continuity check circuit wiring using a high quality

calibration. multimeter. Be sure to maintain the correct polarity

or the sensor will not work.

NOTE: Do NOT use a test light or other instru-

ment; or controller damage may result.

03 Supply Air Temperature Sensor Failure • Check the sensor by selecting it using the RET/SUP

(Check Alarm) key (if necessary). If the display shows [- - - -], the

sensor is defective or the circuit is open or shorted.

• Indicates a problem exists with this sensor

or its wiring. The sensor is reading out-of- • Check sensor by substitution. Be sure sensor

range; or appears to be open or shorted. polarity is correct. Replacement sensor MUST be

calibrated or sensor grade set.

• Sensor Check test detected an out-of-range

condition. • Continuity check circuit wiring using a high quality

multimeter. Be sure to maintain correct polarity or

• This sensor REQUIRES ice bath calibration or the sensor will not work.

correct sensor grade setup.

NOTE: Do NOT use a test light or other

NOTE: If the Supply Air sensor is the instrument; or controller damage may result.

controlling sensor when it fails, the

controller continues unit operation

using the Return Air sensor.
