EPD/HB/40521/000
ISSUE 5
EPD TECHNICAL HANDBOOK Page 36
3.5.10 Displaying/Setting Dose Rate Alarm On/Off Thresholds
To display and/or set dose rate
alarm ON thresholds, press and
hold the button until this top-level
display appears:
Three sub-displays are available (in the following sub-display order):
♦ 1
st
Hp(10)/h Dose Rate Alarm ON
♦ 2
nd
Hp(10)/h Dose Rate Alarm ON
♦ Hp(0.07)/h Dose Rate Alarm ON
To display and/or set dose rate
alarm OFF thresholds, press the
button until this display appears:
Three sub-displays are available:
♦ 1
st
Hp(10)/h Dose Rate Alarm OFF
♦ 2
nd
Hp(10)/h Dose Rate Alarm OFF
♦ Hp(0.07)/h Dose Rate Alarm OFF
The EPD can perform the role of a ‘personal alarming’ EPD with alarm thresholds for
dose rate. There are two Hp(10)/h dose rate alarms and a single Hp(0.07)/h dose
rate alarm that can de displayed. The 2
nd
Hp(10)/h dose alarm has the higher priority
and should always be set to a higher value than the 1
st
Hp(10)/h alarm. The alarm
thresholds can be modified by the user, if required, but only when the EPD default
setting is set to ‘adjustable’. The user is barred from modifying the thresholds if the
EPD default is set to ‘not adjustable’. These default settings can only be set via the
IR communications link.
The dose rate alarm thresholds can be set using the button as follows:
10µSv/h, 50µSv/h, 100µSv/h, 500µSv/h, 1mSv/h, 5mSv/h, 10mSv/h,
50mSv/h, 100mSv/h, 500mSv/h, 1.0Sv/h
