Orion Benchtop pH/ISE Meter Instruction Manual
Use with Accessories
66
E. Use with Strip Chart Recorders
The Orion 520Aplus, 525Aplus, 720Aplus, and 920Aplus can be used with
a strip chart recorder. The audio jack on the rear panel provides an output
for a strip chart recorder of absolute millivolts independent of operating
mode. On the 525Aplus, 720Aplus and 920Aplus this output is for channel
one only.
The voltage provided is a direct uncompensated readout of the electrode
response, set at a one to one ratio.
To interface your recorder to the meter, a 2.5 mm phone plug is required.
The tip (inner) connection should be wired to the high side of the recorder
and the sleeve (outer) connection should be wired to the low side of the
recorder. A Switchcraft type 850 or equivalent phone plug is suggested.
F. Use with DataCOLLECT™
DataCOLLECT can be used with Orion 520Aplus, 525Aplus, 720Aplus,
and 920Aplus.
DataCOLLECT is a program that can be easily installed for your
unattended PC to collect data from Orion’s family ISE, pH, Conductivity
and Dissolved Oxygen (DO) meters from up to 4 serial ports
simultaneously.
This software operates in Windows
®
3.1
†
, Windows 95 an Windows NT
version 4 Platforms.
DataCOLLECT collects the data generated by the meter, which is passed to
the PC via RS232 output. The required computer interface cable, Orion
0ACBLO, is included with the DataCOLLECT software package.
DataCOLLECT also allows you to export the data received into programs
such as Excel
†
, Lotus
††
, and Access
†
for your convenience.
(
†
Registered Trademark of Microsoft Corporation)
(
††
Registered Trademark of Lotus Development Corporation)
