Example) Inspection by re-tightening method.
Retighten the already tightened bolt. （LED will not turn
on at no loading condition.)
When it reaches 7.5% of the maximum torque capacity,
the blue LED turns on.
As torque increases, the blue LED moves toward right.
Stop tightening as the bolt starts to rotate again, and it
reads out the torque value at that moment.
Press MEM key to save the data.
(If the set torque is Zero values, Auto memory/Reset is
not effective.)
Press C key to clear the data.
Cautions)
In case you accidentally apply over 105% of the max
capacity torque.
The applied torque value and "----" appears on LCD
alternately while the red LED blinks and the buzzer
goes off.
In this situation, data saving is not possible by pushing
MEM key.
Blinking
13
Use ▲▼ key to select the lowest end of the data range to delete, and press MD key.
It shows the number of data to delete (Press C key to cancel).
Keep MD key pressed, and press C key, then the selected range of data will be deleted at one time.
The display returns to the measuring condition.
Number of data to delete
⑦ Inspection use by Re-tightening torque method/Loosening torque method (Peak Mode)
In Preset tightening mode or Judgement tightening mode, set the target and lower/upper limit torque to 0.
(Please refer to P19 for setting procedures.)
