Insert AA batteries (2pc) inside the handle of the main body.
Please be careful not to place them at wrong polarity (see below illustration).
Both nickel-hydrogen battery and alkaline battery can be used.
However, nickel-hydrogen battery is more recommendable (See below ※ ).
Please refrain from using a new and old battery together, or different type of batteries at the same time in order to
maintain stable performance.
※ Nickel-hydrogen battery and alkaline battery have different nal voltage.
CPT indicates battery shortage by showing "LOBATT" based on rechargeable nickel-hydrogen battery voltage.
Therefore, when using alkaline batteries, it may show the "LOBATT" display before using up the batteries.
10. Battery
9. External Output
① Communication settings for external output
Synchro system :
asynchronous communication method
Baud rate : 2400/4800/9600/19200bps
Data length : 7bit/8bit
Stop bit : 1 bit
Parity : NONE / EVEN / ODD
② PC output
Connect CPT to PC with the dedicated communication cable (No.585). Set the PC’s baud rate in line with CPT setting.
※ Communication cable(No.585) is sold separately.
External output format
○Preset tightening mode
○Judgement tightening mode
R E ， 5 0 ， 1 0 0 . 0 ， A ， O K C R LF
Alphabetical symbol for the set torque. If the torque is zero, it shows "-".
Header Counter(2g.) Torque(Decimal point) Delimiter
CW : Blank、 CCW : Minus (-)
Judgement result : "LO","OK","HI".When the set torque is zero, or tightening torque is zero, it shows "--".
R E ， 5 0 ， 1 0 0 . 0 C R LF
Header Counter(2g.) Torque(Decimal point)
Delimiter
20
