Tornado BD 14/4 User Manual

GB GB
to flow and the squeegee will start
drying the floor.
8. During the first few feet check
that the solution flow is
appropriate. The flow adjuster of
the solution is already adjusted at
the factory to satisfy the cleaning
of most floors. If it is necessary to
adjust the quantity of solution onto
the floor, adjust the lever of the
flow adjuster (11).
9. When moving the machine
backwards, make sure that the
squeegee is lifted.
Handle bar adjustment
When approaching obstacles or
near walls, it is possible to
simplify the handling of the
machine by adjusting the handle
bar more vertically with respect to
the machine.
To rotate the handle bar:
1. Lift up on the release lever (8)
2. Rotate the handle bar into the
new working position keeping the
release lever (8) pulled.
3. Release the lever (8) to lock
handle bar.
Once the obstacle has been passed
repeat the operation to return to the
previous working position.
This operation is also possible with
the machine in motion by
temporarily holding the handle bar
release levers (8).
Overflow device
In order to avoid serious damages
to the suction motor, the machine
is equipped with a float that
intervenes when the recovery tank
is full, closing the suction hose and
stopping the suction.
When this happens, it is necessary
to empty the recovery tank.
1. Switch off the machine pressing
the main switch.
2. Take off the suction filter cover
(19) after turning the blocking
levers (18).
3. Take off the squeegee hose from
its seat (17).
4. Lift and remove the recovery
tank (16) holding it from the
provided handles, one on the front
and one on the rear of the tank.
Empty the recovery tank into
appropriate containers, according
to the standard norms for the liquid
disposal.
5. Reassemble everything.
ATTENTION:
This operation must be carried out
using gloves to protect from contact
with dangerous solutions.
Security device brush lifting
A security device prevents the
brush motor when, for any reason,
the brush is lifted from the floor
during operation. To check this
operation, push down on the
handle so that the brush is lifted
off of the floor. The brush should
stop rotating. When returned to
the normal working position the
brush should start rotating again.
STOPPING THE MACHINE
AFTER CLEANING
OPERATION
Before carrying out any type of
maintenance:
1. Switch off the main switch (1).
2. Lift the squeegee by rotating the
squeegee lift lever upwards (5).
10
