Tornado BD 14/4 User Manual

GB GB
TECHNICAL DESCRIPTION
with batteries AGM
Cleaning width in 14
Squeegee width in 16
Tension batteries V 24
Capacity of the batteries Ah
5
28
Power installed W 430 (18A)
Working capacity, up to Sq.ft/h 11,300
Brush diameter In 14
Brush rpm Rpm 170
Brush pressure (max) Lbs. 55
Suction vacuum Water lift 36”
Type of drive semi automatic
Maximum gradient % 2
Capacity solution tank Gallon 4
Capacity recovery tank Gallon 4.2
Machine length (min) In 29
Machine height In 21.6
Machine width In 16.3
Machine weight (empty, with batteries) Lbs. 143
Weight of the batteries Lbs. 48
Recharging time max Hour 10
Battery compartment with support (L x W x H) in 8.5 x 10.6 x 7.5
Sound Level dB (A) < 70
Class III
Protection level IP X3
Battery charger V ~ 100-240
Battery charger: frequency Hz 50-60
Battery charger: nominal current A 5
Battery charger: class I
5
