Tornado BD 26/27 User Manual

5
SUMMARY
LEGEND PANEL OF CONTROLS 6 Working in manual mode 16
LEGEND MACHINE 7 Working adjustments 17
TECHNICAL DESCRIPTION 8 Adjustment of the detergent solution ow 17
INTRODUCTORY COMMENT 9 Adjustment of the brushes pressure 17
GENERAL RULES OF SECURITY 9 Electric protection 17
SYMBOLOGY 9 Overow device 18
OPTIONAL ACCESSORIES 10 STOP OF THE MACHINE AFTER CLEANING
OPERATION
18
BEFORE USE 10 DAILY MAINTENANCE 18
Handling of the packed machine 10 Recovery tank emptying and cleaning 18
Unpacking of the machine 10 Suction lter cleaning 18
Access to the battery compartment 10 Brushes cleaning 18
Battery installation 11 Brushes disassembly 18
Battery recharger 11 Squeegee cleaning 19
Incorporated battery recharger (optional) 11 WEEKLY MAINTENANCE 19
Batteries recharging 11 Rear squeegee rubber check 19
Batteries recharging with incorporated charger (optional) 11 Squeegee hose cleaning 19
Batteries disposal 12 Cleaning of solution tank and lter 19
Battery connections and switching on machine 12 TWO-MONTHLY MAINTENANCE 19
Batteries charge level indicator 12 Front squeegee rubber check 19
Setting of the battery check card 12 SIX-MONTHLY MAINTENANCE 19
Hour meter 13 Splash guard rubber check 19
Squeegee assembly 13 Cleaning of the inner lter solution tank 20
Adjustment of the squeegee 13 TROUBLESHOOTING GUIDE 20
Splash guard assembly 13 The suction motor does not work 20
Brushes assembly 14 The brushes motor does not work 20
FLOOR CLEANING 14 The traction motor does not work 20
Recovery tank 14 The water does not come down onto the brush-
es or is insufcient
20
Detergent solution tank 14 The machine does not clean properly 21
3SD system Solution Saving System Dispenser (optional) 14 The squeegee does not dry perfectly 21
STARTING OF THE MACHINE 15 Excessive foam production 21
Forward and backward movement 15 PROGRAMMED MAINTENANCE 21
Horn
16
RECOMMENDED BRUSHES
22
Working brake
16
Parking brake
16
Manual movement of the machine
16
Automatic squeegee lifting in reverse
16
Working in automatic mode
16
