WARNING
Incorrectbatterycableroutingcould
damagethemachineandcablesand
causesparks.Sparkscancausethe
batterygassestoexplode,resultingin
personalinjury.
•Alwaysdisconnectthenegative
(black)batterycablebefore
disconnectingthepositive(red)
cable.
•Alwaysconnectthepositive(red)
batterycablebeforeconnectingthe
negative(black)cable.
WARNING
Batteryterminalsormetaltools
couldshortagainstmetalmachine
components,causingsparks.Sparks
cancausethebatterygassestoexplode,
resultinginpersonalinjury.
•Whenremovingorinstallingthe
battery,donotallowthebattery
terminalstotouchanymetalpartsof
themachine.
•Donotallowmetaltoolstoshort
betweenthebatteryterminalsand
metalpartsofthemachine.
2.Securethepositivecable(red)tothepositive
(+)terminalwithabolt(1/4x5/8inch)anda
locknut(Figure6).
g004027
Figure6
1.Smallblackcable3.Negative(-)batterycable
2.Positive(+)batterycable
3.Securethesmallblackwireandthenegative
cable(black)tothenegative(-)terminalofthe
batterywithabolt(1/4x5/8inch)andlocknut
(1/4inch)(Figure6).
4.Coattheterminalsandmountingfastenerswith
petroleumjellytopreventcorrosion.
5.Slidetherubberbootoverthepositive(+)
terminaltopreventapossibleshortfrom
occurring.
6.Installthetopbatteryhold-downtotheside
batteryhold-downsandsecureitwiththe
washersandwingnuts.
5
InstallingFrontWeights
Partsneededforthisprocedure:
–
Frontweightkit(s)asneeded
Procedure
Thismachinehasbeendesignedinaccordancewith
ANSIB71.4-2017.However,whenattachmentsare
installedonthemachineadditionalweightmaybe
requiredtocomplytothestandards.
1.Usethechartbelowtodeterminethe
combinationsofadditionalweightrequired.
OrderpartsfromyourauthorizedTorodistributor.
AttachmentWeight
Required
WeightKit
KitQuantity
SpikerKit
Rahn
Groomer
23kg(50lb)
PartNo.100-64421
Note:ForModel08705machines,donotinstall
theweightkitifyourmachineisequippedwith
thefrontliftframekit.
2.Installtheweightkit;refertotheInstallation
Instructionsfortheweightkit.
10
