g002724

Figure27

FuelSystem

Maintenance

ReplacingtheFuelFilter

ServiceInterval:Every500hours

Anin-linelterisincorporatedintothefuelline.Use

thefollowingprocedureswhenreplacementbecomes

necessary:

1.Closethefuel-shutoffvalve,loosenthehose

clamponthecarburetorsideofthelter,and

removethefuellinefromthelter(Figure28).

g002729

Figure28

1.Fuellter

2.Hoseclamps

2.Placeadrainpanunderthelter,loosenthe

remaininghoseclamp,andremovethelter.

3.Installthenewlterwiththearrowonthelter

bodypointingawayfromthefueltank(toward

thecarburetor).

4.Slidethehoseclampsontotheendsofthefuel

lines.

5.Pushthefuellinesontothefuellterandsecure

themwiththehoseclamps.

Note:Besurethatthearrowonthesideofthe

lterpointstowardthecarburetor.
