Toro 08703 User Manual

Changingthe
Carbon-CanisterFilter
ServiceInterval:Every500hours
1.Raisetherightreartireofftheground,and
supportthemachinewithjackstands.
2.Removethe4wheelnutsthatsecurethewheel
tothehub,andremovethewheelandtire
(Figure29).
g273203
Figure29
1.Stud(wheelhub)
3.Wheelnuts
2.TireandWheel
3.Removethe4angecapscrews(1/4x5/8inch)
thatsecurethewheelshroudtotheframeofthe
machine(Figure30).
g273204
Figure30
1.Flangecapscrews(1/4x
5/8inch)
2.Wheelshroud
4.Reachingaroundthelower,inboardedgeofthe
console,pullthecarbon-canisterlterrearward
andoutofthehoseattheendofthecarbon
canister(Figure31).
g273202
Figure31
1.Console
3.Hose
2.Carbon-canisterlter4.Carboncanister
5.Insertanewcarbon-canisterlterintothehose
attheendofthecarboncanister(Figure31).
6.Aligntheholesinthewheelshroudwiththe
frameofthemachine(Figure30),andsecure
theshroudtotheframewith4angecapscrews
(1/4x5/8inch)thatyouremovedinstep3.
7.Assemblethetireandwheelintothestudsof
thewheelhub(Figure29)withthe4wheelnuts
thatyouremovedinstep2,andtightenthenuts
byhand.
8.Removethejackstandandlowerthemachine
totheground.
9.Torquethewheelnuts;refertoT orquingthe
WheelLugNuts(page29).
27
