BATTERY
Service Interval/Specification
Check the electrolyte level in the battery every
25 hours. Always keep the battery clean and
fully charged. If the battery terminals are
corroded, clean them with a solution of four
parts water and one part baking soda. Apply a
light coating of grease to the battery terminals
to prevent corrosion.
Voltage/Cold Cranking Amps
Gasoline Engines 12V 380 CCA
Diesel Engines 12V 495 CCA
Removal
1. Disengage the PTO, set the parking brake,
turn the ignition key to OFF and remove the
key.
2. Remove the grille.
3. Remove the battery hold down.
4. Disconnect the negative (black) ground
cable from the battery post.
5. Disconnect the positive (red) cable from the
battery post.
IMPORTANT: Always hold the battery vertical
to avoid spilling battery acid.
WARNING: When removing or installing the
battery, do not allow the battery terminals to
touch any metal parts of the tractor (below the
headlights).
Battery Heat Shield
All gasoline engines are equipped with a heat
shield which is incorporated into the battery
hold down. Replace the heat shield after
servicing to protect the battery from heat.
NOTE: Failure to reinstall the heat shield after
servicing the battery can result in shortened
battery life and/or battery damage.
2.0109.016
2.0109.038
2.0109.012
6
ELECTRICAL
6-4 5xi Series Tractor Service Manual
