Adjusting the Clip Rate
1. Determine the appropriate clip rate per the following table:
Clip Rate
Reel Speed Pulley
Position
Cutting Unit
8-blade 11-blade 14-blade
Low Low 7.3 mm (0.286 inch) 5.3 mm (0.208 inch) 4.2 mm (0.164
inch)
Low High 6.1 mm (0.241 inch) 4.4 mm (0.175 inch) 3.5 mm (0.137
inch)
High Low 5.9 mm (0.233 inch) 4.3 mm (0.169 inch) 3.4 mm (0.133
inch)
High High 5.0 mm (0.196 inch) 3.6 mm (0.142 inch) 2.8 mm (0.112
inch)
2. Adjust the reel speed control to the HIGH or LOW setting as needed.
3. Set the reel-drive pulley on the cutting unit to the H
IGH or LOW position as needed; refer
to your cutting unit Operator’s Manual.
During Operation
During Operation Safety
General Safety
• The owner/operator can prevent and is responsible for accidents that may cause
personal injury or property damage.
• Wear appropriate clothing, including eye protection; long pants; substantial, slip-resistant
footwear; and hearing protection. Tie back long hair and do not wear loose clothing or
loose jewelry.
• Do not operate the machine while ill, tired, or under the influence of alcohol or drugs.
• Use your full attention while operating the machine. Do not engage in any activity that
causes distractions; otherwise, injury or property damage may occur.
• Before you start the machine, ensure that all drives are in neutral, the parking brake is
engaged, and you are in the operating position.
• Keep bystanders and children out of the operating area. If co-workers must be present,
use caution and ensure that the grass basket is installed on the machine.
• Operate the machine only in good visibility to avoid holes or hidden hazards.
• Do not operate the machine when there is the risk of lightning.
• Use care when mowing on wet grass. Poor footing could cause a slip-and-fall accident.
• Keep your hands and feet away from the cutting unit.
3460-887A Page 5–4 Operation: Before Operation
