Operating the Machine after Mowing (continued)
3. Install the grass basket on the machine and transport the machine to storage.
Disengaging the Transmission
You can disengage the drum from the transmission to allow the machine to be maneuvered.
Disengage the transmission when you need to move the machine without starting it (e.g.,
performing maintenance in an enclosed area). Before you operate the machine, ensure that
you engage the transmission.
G404730
Traction-engagement lever—DISENGAGED position
Transmission gearbox
Traction-engagement lever—ENGAGED position
Transporting the Machine
Installing the Transport Wheels
You can purchase an optional Transport Wheel Kit (Model 04123); contact your authorized
Toro distributor.
1. Ensure that the tires are inflated to 83 to 103 kPa (12 to 15 psi).
2. Move the kickstand to the T
RANSPORT-WHEEL-SERVICE position.
Operation: After Operation Page 5–9 3460-887 A
