Installing the Transport Wheels (continued)
G406965
3. Slide a wheel onto an axle .
4. Pivot the wheel-locking clip
away from
center of the wheel, allowing it to slide farther
onto the axle.
5. Rotate the wheel back and forth until it slides
completely onto the axle and the locking clip is
secured in the groove on the axle shaft.
6. Repeat the procedure on the opposite side of
the machine.
7. Carefully lower the machine off the kickstand.
Transporting the Machine Using Transport Wheels
Use the transport wheels to transport the machine a shorter distance.
1. Install the transport wheels.
2. Ensure that the traction and reel-drive controls are in the N
EUTRAL position.
3. Start the engine and set the throttle control to S
LOW.
4. Tip the front of the machine up and gradually engage the traction drive.
5. Adjust the throttle to operate the mower at the desired ground speed and transport the
machine to the desired destination.
Removing the Transport Wheels
1. Release the clutch bail, use the throttle control to lower the engine speed, and shut off
the engine.
2. Move the kickstand to the T
RANSPORT-WHEEL-SERVICE position.
3460-887A Page 5–10 Operation: Transporting the Machine
