Toro Reelmaster 5510 Series User Manual

g006504
Figure22
1.Lead-inchamferonrightendofbedknife
Note:Donotmakethelead-inchamfertoo
largeasitmaycauseturftufting.
ServicingtheBedknife
BedknifeChart
Thebedknifeservicelimitsandgrindanglesarelistedinthefollowingchart.
Important:Operatingthecuttingunitwiththebedknifebelowtheservicelimitmayresultinpoor
after-cutappearanceandreducethestructuralintegrityofthebedknifeforimpacts.
BedknifeDimensionandGrindAngleChart
GrindAngles Bedknife
PartNo.
BedknifeLip
Height*
ServiceLimit*
Top/FrontAngles
5.6mm4.8mm
LowHOC(Optional)
110-4084
(0.220inch)(0.190inch)
5°/5°
5.6mm4.8mm
ExtendedLowHOC(Optional)
120-1640
(0.220inch)(0.190inch)
7°/10°
5.6mm4.8mm
ExtendedLowHOCEdgeMax®
(Optional)
119-4280
(0.220inch)(0.190inch)
7°/10°
EdgeMax®LowHOC
5.6mm4.8mm
(ProductionforModel03693)
127-7132
(0.220inch)(0.190inch)
10°/5°
EdgeMax®
6.9mm4.8mm
(ProductionforModels03696
and03697)
108-9095
(0.270inch)(0.190inch)
5°/5°
6.9mm4.8mm
Standard(Optional)
108-9096
(0.270inch)(0.190inch)
5°/5°
9.3mm4.8mm
HeavyDuty(Optional)
110-4074
(0.370inch)(0.190inch)
5°/5°
*WarmseasongrassesmayrequirethelowHOCbedknifefor12.7mm(0.500inches)andbelow.
16
