g003318
Figure3
1.Cuttingunitkickstand
3
AdjustingtheRearShield
NoPartsRequired
Procedure
Undermostconditions,thecuttingunitproduces
bestdispersionwhenyouclosetherearshield(front
discharge).Whenconditionsareheavyorwet,you
mayopentherearshield.
Toopentherearshield(Figure4),loosenthecap
screwsecuringtheshieldtotheleftsideplate,rotate
theshieldtotheopenpositionandtightenthecap
screw.
g003316
Figure4
1.Rearshield
2.Capscrew
4
MountingtheCounter
Weights
NoPartsRequired
Procedure
Allcuttingunitsareshippedwiththecounterweight
mountedtotheleftendofthecuttingunit.Usethe
followingdiagramtodeterminethepositionofthe
counterweightsandreelmotors.
g003319
Figure5
1.Onthe#2and#4cuttingunits,removethe2
capscrewssecuringthecounterweighttothe
leftendofthecuttingunit.
2.Removethecounterweight(Figure6).
6
