Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Cuttingunit
1Inspectthecuttingunit.
2
Nopartsrequired
–
Usethekickstandwhentippingthe
cuttingunit.
3
Nopartsrequired
–
Adjusttherearshield.
4
Nopartsrequired
–
Mountthecounterweights.
MediaandAdditionalParts
Description
Qty.
Use
PartsCatalog
1
Operator'sManual
1
Reviewthematerialandsaveitinanappropriateplace.
O-ring
1Mountthereelmotortothecuttingunit.
Screws
2Mountthereelmotortothecuttingunit.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
1
InspectingtheCuttingUnit
Partsneededforthisprocedure:
1
Cuttingunit
Procedure
1.Checkeachendofthereelforgrease.
Note:Greaseshouldbevisiblyevidentinthe
reelbearingsandinternalsplinesofthereel
shaft.
2.Ensurethatallnutsandboltsaresecurely
tightened.
3.Makesurethecarrierframesuspension
operatesfreelyanddoesnotbindwhenmoved
backandforth.
2
UsingtheCuttingUnit
Kickstand
NoPartsRequired
Procedure
Wheneveryoumusttipthecuttingunittoexposethe
bedknife/reel,propuptherearofthecuttingunitwith
thekickstand(suppliedwiththetractionunit)toensure
thatthenutsonthebackendofthebedbaradjusting
screwsarenotrestingontheworksurface(Figure3).
