Toro Reelmaster 5510 Series User Manual

g003320
Figure6
1.Counterweight
3.Onrightendofcuttingunit,removetheplastic
plugfromthebearinghousing(Figure7).
4.Removethe2capscrewsfromtherightside
plate(Figure7).
g003321
Figure7
1.Plasticplug
2.Capscrew(2)
5.Installthecounterweighttotherightendof
thecuttingunitwiththe2screwspreviously
removed.
6.Looselyinstallthe2reelmotormountingcap
screwstotheleftsideplateofthecuttingunit
(Figure7).
ProductOverview
Specications
CuttingUnit
Weight
8Blade
67kg(147lb)
11Blade
69kg(151lb)
CuttingUnitAccessoriesandKits
Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineT oro
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.
Note:SeethePartsCatalogforpartnumbers.
Note:Allaccessoriesandkitsare1percuttingunit
unlessotherwisespecied.
GrassBasketKit:Aseriesofclippingcollection
basketsattachedtothefrontofthecuttingunitsto
collectgrassclippings
RearLiftCylinderKit:Collarsassembledonrear
cuttingunitliftarmcylinderslimittheheightofthe
cuttingunits.Thisincreasestheareafortherear
grassbaskets.
RearRollerBrushKit:Ahigh-speed,high-contact
brushkeepstherearrollerfreeofgrassanddebris,
whichmaintainsaconsistentheightofcutand
preventsclumping.Thisleadstoabetterafter-cut
appearance.
GroomerKit:Rotatingbladesassembledbehind
thefrontrollerprovidethebestmethodforreducing
grainandspongyturfbystandingupthegrass
beforecutting.Thegroomeralsoknocksoffdewfor
decreasedstickinessandclumping,opensupcanopy
forbettergrassclippingintegration,andliftsgrassfor
aclean,crispcut.Theoveralldesignimprovesthe
qualityofcutforhealthierturfgrasswhileimproving
theafter-cutappearance.
BroomerKit:Multiplebrushstripswovenintothe
helicalgroomerbladesimprovetheeffectiveness
ofthegroomerkit.Performanceofthegroomer
isenhancedbyenablingafullwidth"brooming"
effectoftheturfwhileopeningupthecanopyfor
bettergrass-clippingintegration.Thecombinationof
groomerandbroomersystemsoptimizethequality
ofcutandafter-cutappearanceformoreconsistent
playingconditions.
Comb/ScraperKit:Axedcombinstalledbehind
thefrontrollerhelpsreducegrainandspongyturfby
standingupthegrassbeforecutting.Ascraperforthe
frontWiehlerollerisincludedinthekit.
7
