Toro Sand Pro 2040Z - Fuel System Maintenance

FuelSystem
Maintenance
ReplacingtheCarbon-Canister
Filter
ServiceInterval:Every200hours
1.Removethefastenerssecuringtheseatassemblytothe
machine.
G023891
1
2
3
Figure46
1.Seatassembly3.Washer(4)
2.Bolt(4)
2.Disconnectthelterfromthecarboncanister(Figure
47).
1
G023990
Figure47
1.Carbon-canisterlter
3.Connectthenewltertothecarboncanister.
4.Installtheseatsupportplateandtheseat.
ReplacingtheFuelFilter
ServiceInterval:Every800hours
Thefuellinehasanin-linelter.Replaceitasfollows:
1.Loosenthehoseclamponthecarburetorsideofthe
lter,andremovethefuellinefromthelter(Figure
48andFigure49).
1
G023448
Figure48
1.Fuellter
G008963
12
3
Figure49
1.Fuellter
3.Fuelline
2.Hoseclamp(2)
2.Placeadrainpanunderthelter,loosentheremaining
hoseclamp,andremovethelter.
3.Slidethehoseclampsontotheendsofthefuellines.
4.Pushthefuellinesontothenewfuellter,andsecure
themwiththehoseclamps.
40
