Toro Sand Pro 2040Z User Manual

HydraulicSystem
Maintenance
CheckingtheHydraulic
System
Wheneveryourepairorreplaceahydrauliccomponent,
youshouldreplacethehydraulic-uidltersandcheckthe
hydraulicsystemtoensurethatitworksproperly.
Important:Makesurethatthehydraulicreservoirsand
themanifoldlterarelledwithuidatalltimeswhen
checkingthehydraulicsystem.
1.Parkthemachineonalevelsurfaceandturntheengine
off.
2.Raiseall3wheelsofthemachineupofftheoor,and
supportthemachinewithjackstandsjusthighenough
toallowthedrivewheelstoturnfreely;refertoLifting
theMachine(page35).
WARNING
Mechanicalorhydraulicjacksmayfailto
supportthemachineandcauseseriousinjury.
Usejackstandswhensupportingthemachine.
3.Starttheengineandsetthethrottletoallowtheengine
torunatlowidle.
4.Movethecontrolhandlestothefull-forwardposition,
andwatchforthedrivewheelstoturnsmoothly.
5.Movethecontrolhandlestothefull-reverseposition,
andwatchforthedrivewheelstoturnsmoothly.
6.Presstheattachmentswitchuntilthelift-cylinderrod
movesinandoutseveraltimes.
Ifthecylinderroddoesnotmoveafter10to15
seconds,orifthepumpmakesabnormalsounds,stop
theengineimmediatelyanddeterminethecauseor
problem.
Inspectforthefollowingconditions,andmake
thenecessaryrepairsorseeyourAuthorizedToro
Distributor:
•Thebeltisremovedorseverelyworn.
•Theuidlevelisinadequate.
•Ahydrauliclterisloose.
•Thechargepumpisworn.
•Thechargerelieflterisworn.
•Thereisanissuewiththeswitchorthewiring.
•Thesolenoidvalveisplugged.
ChangingtheHydraulicFluid
andFilters
ServiceInterval:Aftertherst8hours
Every400hours
Capacity:
•Leftside—1.9L(2.0USqt)
•Rightside—2.0L(2.1USqt)
FluidType:ToroPremiumTransmission/HydraulicTractor
FluidorMobiluid
®
424
1.Parkthemachineonalevelsurface,stoptheengine,
andremovethekey.
2.Lowertheattachmentlift.
3.Placeadrainpanunderthelefthydrostatic
transmission.
4.Removethedrainplugonthepumpsideandthedrain
plugonthegearside(Figure70),andallowtheoilto
draincompletely.
1
24 32
G023456
Figure70
1.Filtercaps
3.Manifoldlter
2.Drainplug—gearside4.Drainplug—pumpside
5.Removetheltercap,andpullthelteroutofthe
transmission(Figure71).
51
