Figure58
1.Tensionerassembly2.Nut
6.Removetheboltsecuringtheoldtensionerpulleyto
thetensionerarm,andinstallanewpulley(Figure59).
Figure59
1.Bolt4.Pulley
2.Spacer
5.Tensionerarm
3.Seal
7.Removethebeltfromthetransmissionpulleysandthe
enginepulley.
8.Installthenewbeltaroundtheenginepulleyandthe2
transmissionpulleys.
9.Installthespringonthetensionerarmandtheframe
(Figure57).
10.Usearatchetinthesquareholeinthetensionerarmto
temporarilystretchthetensionerspring,andalignthe
belttothetensionerpulley.
ControlsSystem
Maintenance
AdjustingtheControl-Handle
Position
Thereare2heightpositionsforthecontrolhandles;high
andlow .
1.Movethecontrolhandlestotheneutral-locked
position,andsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
3.Loosentheboltsandangenutsthatattachthehandles
tothelevers(Figure60).
Figure60
1.Bolt3.Lever
2.Controlhandle
4.Flangenut
4.Alignthefront-to-rearpositionofthehandlesby
bringingthemtogethertotheneutralposition,and
slidingthemuntiltheyarealigned(Figure61).
46
