Figure7
1.Gastankbody
3.Filltohere,approximately
2.Gastankneck4.Gastankopening
CheckingtheEngineOilLevel
Beforeyoustarttheengineandusethemachine,check
theoillevelintheenginecrankcase;refertoChecking
theOilLevelinEngineMaintenance,page24.
StartingtheEngine
1.Sitdownontheseatandmovethemotioncontrols
outwardtotheparkposition.
2.Disengagethebladesbymovingthebladecontrol
switchtoOff(Figure8).
1
2
G005056
1
2
Figure8
1.Controlpanel2.Bladecontrolswitch—Off
position
3.MovethethrottlelevertoChokebeforestartinga
coldengine(Figure10).
Note:Awarmorhotenginemaynotrequire
choking.
1
2
2
3
4
5
6
G005057
1
2
2
3
4
5
6
Figure9
1.Controlpanel
4.Fast
2.Throttle/choke
lever—chokeposition
5.Continuousvariable
setting
3.Choke6.Slow
4.TurntheignitionkeytoStarttoenergizethestarter.
Whentheenginestarts,releasethekey(Figure10).
Important:Donotengagethestarterformore
than10secondsatatime.Iftheenginefails
tostart,allowa60secondcool-downperiod
betweenattempts.Failuretofollowthese
instructionscanburnoutthestartermotor.
