ReplacingtheGrassDeector
Anuncovereddischargeopeningcouldallow
thelawnmowertothrowobjectsinthe
operator’sorbystander’sdirectionandresult
inseriousinjury.Also,contactwiththeblade
couldoccur.
Neveroperatethelawnmowerunlessyouinstall
acoverplate,amulchplate,oragrasschute
andcatcher.
1.LocateitemsshowninFigure47.
2.Removethenut(3/8inch)fromtherodunderthe
mower(Figure47).
3.Slidetherodoutoftheshortstand-off,spring,and
grassdeector(Figure47).Removethedamaged
orworngrassdeector.
4.Replacethegrassdeector(Figure47).
5.Sliderod,straightend,throughthereargrass
deectorbracket.
6.Placethespringontherod,withendwiresdown,
andbetweenthegrassdeectorbrackets.Sliderod
throughsecondgrassdeectorbracket(Figure47).
7.Insertrodatfrontofgrassdeectorintoshort
stand-offondeck.Securerearendofrodintothe
mowerwithanut(3/8inch)(Figure47).
Important:Thegrassdeectormustbespring
loadedinthedownposition.Liftthedeector
uptotestthatitsnapstothefulldownposition.
G005192
1
2
3
4
5
6
7
Figure47
1.Mowerdeck5.Rod
2.Grassdeector6.Nut(3/8inch)
3.Grassdeectorbracket7.Shortstand-off
4.Spring
36

Toro TimeCutter Z5000 74391 Specifications

General

Cutting Width	50 inches
Transmission	Hydrostatic
Deck Material	10-gauge steel
Number of Blades	3
Type	Zero-Turn Mower
Speed	7 mph forward, 3 mph reverse
Cutting Height	1.5 - 4.5 inches
Warranty	3-year limited
Fuel Capacity	3 gallons
