Toro TimeCutter Z5000 74391 User Manual

RemovingtheBlades
Thebladesmustbereplacedifasolidobjectishit,
ifthebladeisoutofbalance,orthebladeisbent.
Toensureoptimumperformanceandcontinued
safetyconformanceofthemachine,usegenuineToro
replacementblades.Replacementbladesmadebyother
manufacturersmayresultinnon-conformancewith
safetystandards.
Holdthebladeendusingaragorthickly-paddedglove.
Removethebladebolt,curvedwasher,bladestiffener,
andbladefromthespindleshaft(Figure37).
Figure37
1.Sailareaofblade
4.Bladebolt
2.Blade
5.Bladestiffener
3.Curvedwasher
SharpeningtheBlades
1.Usealetosharpenthecuttingedgeatbothends
oftheblade(Figure38).Maintaintheoriginalangle.
Thebladeretainsitsbalanceifthesameamountof
materialisremovedfrombothcuttingedges.
Figure38
1.Sharpenatoriginalangle
2.Checkthebalanceofthebladebyputtingitona
bladebalancer(Figure39).Ifthebladestaysina
horizontalposition,thebladeisbalancedandcanbe
used.Ifthebladeisnotbalanced,lesomemetaloff
theendofthesailareaonly(Figure38).Repeatthis
procedureuntilthebladeisbalanced.
Figure39
1.Blade2.Balancer
InstallingtheBlades
1.Installthebladeontothespindleshaft(Figure37).
Important:Thecurvedpartoftheblademust
bepointingupwardtowardtheinsideofthe
mowertoensurepropercutting.
2.Installthebladestiffener,thecurvedwasher(cupped
sidetowardtheblade)andthebladebolt(Figure37).
3.Torquethebladeboltto35-65ft-lb(47-88N-m).
LevelingtheMowerfrom
Side-to-Side
Themowerbladesmustbelevelfromsidetoside.
Checktheside-to-sidelevelanytimeyouinstallthe
mowerorwhenyouseeanunevencutonyourlawn.
1.Parkthemachineonalevelsurfaceanddisengage
thebladecontrolswitch.
2.Movethemotioncontrolleversoutwardtothe
parkposition,stoptheengine,removethekey,and
waitforallmovingpartstostopbeforeleavingthe
operatingposition.
3.Checktheairpressureofallfourtires.Ifneeded,
adjusttotherecommendedination;referto
CheckingtheTirePressureinDriveSystem
Maintenance,page30.
4.Settheheight-of-cutlevertopositionD
[3inch(76mm)].
5.Carefullyrotatetheblade(s)sidetoside(Figure40).
Ifbothmeasurementsarenotwithin3/16inch
(5mm),anadjustmentisrequired;continuewiththis
procedure.
32

Toro TimeCutter Z5000 74391 Specifications

General

Cutting Width	50 inches
Transmission	Hydrostatic
Deck Material	10-gauge steel
Number of Blades	3
Type	Zero-Turn Mower
Speed	7 mph forward, 3 mph reverse
Cutting Height	1.5 - 4.5 inches
Warranty	3-year limited
Fuel Capacity	3 gallons
