InstallingtheBattery
1.Positionthebatteryinthetraywiththeterminal
poststowardtheoperatingposition(Figure31).
2.Installthepositive(red)batterycabletothepositive
(+)batteryterminalusingthefastenersremoved
previously.
3.Installthenegativebatterycabletothenegative
(-)batteryterminalusingthefastenersremoved
previously.
4.Slidetheredterminalbootontothepositive(red)
batterypost.
5.Securethebatterywiththehold-down(Figure31).
6.Installtheleftsideconsole.RefertheAccessingthe
BatteryprocedureinPremaintenanceProcedures,
page23forinstructions.
ServicingtheFuses
Theelectricalsystemisprotectedbyfuses.Itrequires
nomaintenance;however,ifafuseblows,checkthe
component/circuitforamalfunctionorshort.
Fuse:
•MainF1-30amp,blade-type
•ChargeCircuitF2-25amp,blade-type
1.Raisetheseattogainaccesstothefuseholder
(Figure33).
2.Toreplaceafuse,pulloutonthefusetoremoveit
(Figure33).
G005073
1
2
Figure33
1.Main-30amp
2.Chargecircuit-25amp
DriveSystem
Maintenance
CheckingtheTirePressure
ServiceInterval:Every25hours—Checktirepressure.
Maintaintheairpressureinthefrontandreartiresas
specied.Uneventirepressurecancauseunevencut.
Checkthepressureatthevalvestem(Figure34).Check
thetireswhentheyarecoldtogetthemostaccurate
pressurereading.
RearTires:13psi(90kPa)
FrontTires(casterwheels):20psi(138kPa)
Figure34
1.Valvestem
30
