Operating Manual Cruise 2.0 R / 4.0 R
8. Starting up
8.1 Fitting the drive onto the boat
• Pleaseensurethatthekickleveratthetransommountisinthe“Lock”
position until the outboard is fitted onto the boat.
• Donotlaythecablearoundsharpedges.
1. Remove the parts supplied with the Cruise R from the packaging.
2. Hang the drive on the transom or motor holder on your boat and tighten the two
mounting clamps.
3. As an alternative the drive can be screwed with four screws (Ø 8 mm / 0.3 inches,
not supplied) through the holes in the clamping mechanism onto the boat’s transom
mount.
4. The following steps are required to set the engine
perfectly to the water surface (trimming):
•Firsttiltthemotorup.Todosothekicklever
must be in the “Tilt/Auto kick-up” position.

Torqeedo Cruise 0.8 R Specifications

General

Brand	Torqeedo
Model	Cruise 0.8 R
Category	Outboard Motor
Language	English
