32
Operating Manual Cruise 2.0 R / 4.0 R
11.2 Changing the propeller
1. Set the main battery switch to the “off” position.
2. Loosen and unscrew the self-locking hexagon nut on the propeller.
3. Pull the propeller with the external disk from the motor shaft.
4. Pull the cylinder pin from the motor shaft and remove the internal disk from the motor
shaft.
5. Set the main battery switch to the “on” position. Allow the motor to run slowly and
check whether the shaft is turning unevenly at the shaft sealant ring.
Contact Torqeedo Service if the shaft is damaged or uneven.
6. Set the main battery switch to the “off” position. Insert the new cylinder pin centrally to
the motor shaft and insert the internal disk onto the motor shaft.
7. Place the propeller onto the motor shaft and turn the propeller until the cylinder pin fits
into the groove of the propeller.
8. Place the external disk over the motor shaft and screw the self-locking hexagon nut
onto the shaft.
11.3 Other care instructions
To clean the motor you can use any cleaning agents suitable for plastic - follow the
manufacturer’s instructions. Cockpit sprays available for cars achieve good results on the
plastic surfaces of the Torqeedo Cruise.
Self-locking
hexagon nut M10
External disk Ø 10.5 mm
Internal disk Ø 10.5 mm
Pin Ø 5 x 10 mm
