10
English
Format Resolution V. Frequency H. Frequency Pixel Clock Frequency
480i 720 x 480i 60Hz 15.734KHz 27MHz
480p 720 x 480p 60Hz 31.5KHz 27MHz / 27.027MHz
576i 720 x 576i 50Hz 15.625KHz 27MHz
576p 720 x 576p 50Hz 31.25KHz 54MHz
720p 1280 x 720p 50Hz 37.5KHz 74.25MHz
720p 1280 x 720p 59.94Hz / 60Hz 44.9KHz / 45KHz 74.17MHz / 74.25MHz
1080i 1920 x 1080i 50Hz 28.125KHz 74.25MHz
1080i 1920 x 1080i 59.94Hz / 60Hz 33.72KHz / 33.75KHz 74.17MHz / 74.25MHz
1080p 1920 x 1080p 50Hz 56.25KHz 148.5MHz
1080p 1920 x 1080p 59.94Hz / 60Hz 67.432KHz / 67.5KHz 148.35MHz / 148.5MHz
1080p 1920 x 1080p 24Hz / 25Hz 27KHz / 28.125KHz 74.25MHz / 74.25MHz
1080p 1920 x 1080p 30Hz 33.75KHz 74.25MHz
Acceptable Video signals through HDMI terminals
Format Resolution V. Frequency H. Frequency Pixel Clock Frequency
VGA 640 x 480 59.9Hz 31.469KHz 25.175MHz
VGA 640 x 480 72.8Hz 37.861KHz 31.5MHz
VGA 640 x 480 75Hz 37.5KHz 31.5MHz
VGA 720 x 400 70Hz 31.469KHz 28.322MHz
SVGA 800 x 600 56.2Hz 35.156KHz 36MHz
SVGA 800 x 600 60.3Hz 37.879KHz 40MHz
SVGA 800 x 600 72.1Hz 48.077KHz 50MHz
SVGA 800 x 600 75Hz 46.875KHz 49.5MHz
XGA 1024 x 768 60Hz 48.363KHz 65MHz
XGA 1024 x 768 70Hz 56.476KHz 75MHz
XGA 1024 x 768 75Hz 60.023KHz 78.75MHz
WXGA 1280 x 720 59.8Hz 44.772KHz 74.25MHz
WXGA 1280 x 768 59.8Hz 44.776KHz 79.5MHz
WXGA 1360 x 768 60Hz 47.712KHz 85.5MHz
SXGA 1280x1024 60Hz 63.981KHz 108MHz
SXGA 1280x1024 75Hz 79.976KHz 135MHz
Acceptable PC signals through HDMI-1/D-SUB terminals
HDMI, the HDMI Logo, and High-Deîżnition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the
United States and other countries.
Note 1 : HDMI 1 terminal supports PC signal input; HDMI 2 and 3 do not support PC signal.
Note 2 : For PC input, for only supported PC signal can show the correct resolution on TV display.
