2060, 2860/70 ADJUSTMENT 1 - 12 Dec. 1996 © TOSHIBA CORP.
*4
Code
Name
Allowable
Remarks
No. input value
60 Lens position adjustment (100%) 0–40 20
61 Mirror position adjustment (100%) 0–40 20
62 Lens position adjustment (200%) 0–40 20
63 Mirror position adjustment (200%) 0–40 20
64 Lens position adjustment (50%) 0–40 20
65 Mirror position adjustment (50%) 0–40 20
80 Aligning value (lower feeder long) 0–31 20
81 Aligning value (manual) 0–31 24
82 Aligning value (upper feeder long) 0–31 20
83 Aligning value (ADU feed long) 0–31 20
84 ADF aligning value (1st page) 0–15 8
85 ADF aligning value (2nd page) 0–15 8
87
ADF aligning value (2 in 1 original gap)
0–15 8
90 Auto-toner sensor adjustment value 0–255 128
92 Aligning value (PFP) 0–31 20
93 Aligning value (LCF) 0–31 20
94 Aligning value (lower feeder short) 0–31 16
95 Aligning value (upper feeder short) 0–31 16
96 Aligning value (ADU feed short) 0–31 16
97 ADF EEPROM Initialize and – –
automatic adjustment for ADF sensor
Each increase by “1” moves the lens toward
enlargement.
The adjustment sequence must be
61 ⇔ 60 → 63 ⇔ 62 → 65 ⇔ 64
Each increase by “1” causes the paper to
bend more.
Each increase by “1” the original moves
toward the exit side of DF.
Each increase by “1” the original moves
toward the exit side of DF.
Each increase by “1” the gap between
originals increases.
The auto-toner adjustment value is indicated.
Each increase by “1” causes the paper to
bend more.
Initial value*
* Initial value means memory initialization value.
*5 Remove developer for adjustment.
