Toshiba 2060 Service Manual

2060, 2860/70 ADJUSTMENT 1 - 14 Dec. 1996 © TOSHIBA CORP.
Code
Name
Allowable
Remarks
No. input value
18 Default ADF mode 0–1 0
19 Default Sorter mode 0–3 0
20 Default edge erasing mode 0–2 2
21 Auto cassette change 0–1 1
22 Default APS mode 0–2 0
23 Detection of manually placed original 0–1 0
25 Guide Bias control selection 0–1 0
27 ADF’s APS mode 0–2 0
28 Pressing PRINT-KEY after suspension 0–2 0
of APS/AMS
31 Paper size (LCF) 0–14 3, 4
35 Cassette/ADU connect 0–3 0
36 PFP connect 0–4 0
37 Order of sorter key selection 0–1 0
38 Heat-roller temperature setting 0–11 5
value (energy saving)
43 Resettable counter display/ 0–3 0
Original counter display
44 All clear after copy 0–1 0
47 Pre-run time setting value 0–18 3
48 Width of erased area by LED eraser 0–1 0
array (51, 54, 58%)
51 UA mode selection 0–1 0
52 Quick copy mode 0–1 0–1
53 Exposure burnout detection 0–2 0
54 Coin controller mode 0–2 0
0 : ADF mode, 1 : SDF mode
0 : non sort, 1 : staple, 2 : sort, 3 : group
0 : non edge erasing, 1 : Edge erasing,
2 : Auto edge erasing
0 : deactivated, 1 : activated
0 : manual, 1 : APS, 2 : AMS
0 : activated, 1 : deactivated
0 : activate Guide Bias control,
1 : deactivate Guide Bias (always off)
0 : detects every original,
1 : detects only the first original,
2 : prevents copying blank originals
0 : accept (copy start), 1 : refuse 1st pressing
(accept 2nd pressing), 2 : copy disable
3 : LT (UC), 4 : A4 (EUR, OTHER)
0 : Auto-detection, 1 : cassette, 2 : ADU,
3 : No connection
0 : Auto-detection, 1 : 1-cassette,
2 : 2-cassettes, 3 : 3-cassettes,
4 : No connection
0 : sort → staple → group → non sort,
1 : staple → sort → group → non sort
0 : off, 1 : 110 °C, 2 : 120 °C, 3 : 130 °C,
4 : 140 °C, 5 : 150 °C, 6 : 160 °C, 7 : 170 °C,
8 : 180 °C, 9 : 190 °C, 10 : 200 °C,
11 : 210 °C
0 : deactivated, 1 : resettable counter display,
2 : original counter display, 3 : both
0 : deactivated, 1 : activated
0 : off, 1 : 5 sec., 2 : 10 sec., 3 : 15 sec., 4 : 20
sec., 5 : 25 sec., 6 : 30 sec., 7 : 40 sec., 8 : 50
sec., 9 :60 sec., 10 : 70 sec., 11 : 80 sec., 12: 90
sec., 13 : 100 sec., 14 : 110 sec., 15 : 120 sec., 16
: 130 sec., 17 : 140 sec., 18 : 150 sec.
0 : Wide, 1 : Narrow
0 : deactivated, 1 : activated
0 : deactivated (EUR, OTHER), 1 : activated (UC)
0 : activated at all times, 1 : activated only at
automatic exposure, 2 : deactivated
0 : deactivated, 1 : activated (when ENABLE
signal = Low, large size copy is prohibited), 2
: activated (when ENABLE signal = Low,
large size copy or non 100% copy is
prohibited)
Initial Value*
