4.Using the IP Fax Function
Using the IP Fax Function from the Touch Panel 53
Using the IP Fax Function
Checking the network
Two functions are available for checking the network status: ping and traceroute.
There are two ways to select the server you want to check.
To select the desired server from the server list displayed on the touch panel:
Checkable servers and supported protocols are as follows.
Primary DNS server (IPv4/IPv6)
Secondary DNS server (IPv4/IPv6)
Primary WINS server (IPv4)
Secondary WINS server (IPv4)
SMTP server (IPv4/IPv6)
POP3 server (IPv4/IPv6)
Primary SNTP server (IPv4/IPv6)
Secondary SNTP server (IPv4/IPv6)
LDAP server 1
LDAP server 2
LDAP server 3
LDAP server 4
LDAP server 5
Remote server 1
Remote server 2
Primary registrar SIP server
Secondary registrar SIP server
Primary proxy SIP server
Secondary Proxy SIP server
To designate the desired server manually:
Enter the server name, IPv4 address, or IPv6 address manually.
When you have entered a WINS name for the network path of the remote server 1/2 in TopAccess “Save as file
Setting”, you will not be able to perform network check on those servers by selecting them from the server list. In
this case, designate the IP address of the remote server 1/2 manually to perform the network check.
When the ping/traceroute command can reach a server, the IP address is displayed for the check result for the
server. If the command cannot reach it for some reason, the host name is displayed instead of the IP address.
Item name Description
Server Select the server you want to check.
PING Press this button to check the connection status between this equipment and the
servers on the network.
TRACEROUTE Press this button to view and check the network path to the desired server.
