– 50 –
2-3. Outdoor Inverter
(50Hz model: MMY-MAP
∗∗∗
4FT8-E, MAP
∗∗∗
4FT8-TR, MAP
∗∗∗
4FT8)
No. Parts Name Model Specification
MMY-MAP
0804FT8
∗
1004FT8
∗
1204FT8
∗
1404FT8
∗
7 Line filter — 2.71mH/AC400V/35A
3 Communication terminal block JXO-B2H AC30V (or no more
than DC42V) / 1A, 6P
10 Fuse (MCC-1596) GAC1 31.5A 31.5A/AC500V
11 Comp. motor drive IPM
(MCC-1596)
PS22A76 25A/DC1200V
14 Fan motor drive IPM
(MCC-1610)
FSBB20CH60C 20A/DC600V
16 PTC thermistor MZ32-
101RMARD01E
13A/AC500V
17 Pipe temp. sensor (TD) — -30˚C – 135˚C
(Ambient temp. range)
18 Pipe temp. sensor (TS) — -20˚C – 80˚C
(Ambient temp. range)
19 Heat exchanger temp.
sensor (TE)
— -20˚C – 80˚C
(Ambient temp. range)
20 Outside temp. sensor (TO) — -20˚C – 80˚C
(Ambient temp. range)
21 Oil temp. sensor (TK) — -30˚C – 135˚C
(Ambient temp. range)
22 Liquid temp. sensor (TL) — -20˚C – 80˚C
(Ambient temp. range)
6 P.C. board (Noise filter) MCC-1608 —
12 P.C. Board (IPDU for fan) MCC-1610 —
13 Fuse (MCC-1610) GDT250V15A 15A/AC250V
15 Magnet switch (50Hz) FC-1S AC220-240V
8 P.C. board (I/F board) MCC-1606 —
9 P.C. board (IPDU for Comp.) MCC-1596 —
4 Reactor (For comp.) CH-79 5.8mH/16A
5 Reactor (For fan) CH-55 5.8mH/14A
1 Power supply terminal block JXO-6004 AC600V/75A,4P
2
Relay terminal block for reactor
JXO-6B AC250V/20A,6P
